Explore Salus NGS Platforms
  • Reads / Run
    25 M / 60 M / 100 M
    Data Output / Run
    1.25 Gb ~ 40 Gb
    Run Time
    3.4 hr ~ 25 hr
    Applications
    Personalized diagnostics, NIPT, forensics, eDNA, targeted-NGS, etc.
    • Highlighted Features
    • Specifications
    • Applications
    • Ordering Information
    • Instrument Specifications

    Sequencing Reagent Set Read Length Data Output Time Q30
    25M SE400 10.0 Gb 18 hr ≥ 80%
    PE300
    		 15.0 Gb 25 hr ≥ 80%
    SE50 1.25 Gb 3.4 hr ≥ 90%
    SE75
    		 1.875 Gb 4.1 hr ≥ 90%
    SE100
    		 2.5 Gb 4.7 hr ≥ 90%
    PE150 7.5 Gb 10.9 hr ≥ 90%
    60M SE50 3.0 Gb 3.7 hr ≥ 90%
    SE75 4.5 Gb 4.5 hr ≥ 90%
    SE100 6.0 Gb 5.4 hr ≥ 90%
    PE150 18.0 Gb 12 hr ≥ 90%
    100M SE50 5.0 Gb 3.8 hr ≥ 90%
    SE75 7.5 Gb 4.6 hr ≥ 90%
    SE100 10.0 Gb 5.5 *hr ≥ 90%
    PE150
    		 30.0 Gb
    		 13.2 hr ≥ 90%
    SE400 40.0 Gb 20.5 hr ≥ 80%

    *The sequencing time is for dual index (8+8);

    *Sequencing time and data quality may fluctuate due to the different libraries used


    Methods Applications Data volume / sample Read Length 25M
    Samples / run     		60M
    Samples / run     		100M
    Samples / run
    Low-pass Whole Genome Sequencing NIPT ~5M reads SE50 5 12
    		 20
    Targeted Sequencing
    (Capture / Multiplex Amplification)         		Targeted Pathogen Sequencing (tNGS) 0.5M ~ 1M reads SE50 25 / 50 60 / 120
    		 100 / 200
    Small Panel for Tumor Companion diagnostics ~1 Gb PE150 7 18 30
    Small Panel for Genetic diseases (Deafness, Metabolism) 3 ~ 5 Gb PE150 1 ~ 2 3 ~ 6 6 ~ 10
    16S Sequencing ~0.5M reads PE300 50 / /
    Forensic DNA Identification ~0.5M reads SE400 50 / 200
    Small Genome Sequencing
    (Tuberculosis, Influenza, etc.)         		Bacterial / Virus ~1 Gb PE150 7 18 30
    Methylation Sequencing Pan-cancer early screening ~4 Gb PE150 2 4 7

    *The number of samples is estimated after careful consideration of library pooling bias and is for reference only.
    Explore more
    Products Product Code

    Saluseq Nimbo Sequencing Reagent Set（SRL-SE50-25M）

    		SL-S00902

    Saluseq Nimbo Sequencing Reagent Set（PRL-PE150-25M）

    		SL-S00915

    Saluseq Nimbo Sequencing Reagent Set（SRL-SE50-60M）

    		SL-S00917

    Saluseq Nimbo Sequencing Reagent Set（PRL-PE150-60M）

    		SL-S00929

    Saluseq Nimbo Sequencing Reagent Set（SRL-SE50-100M）

    		SL-S01543

    Saluseq Nimbo Sequencing Reagent Set（PRL-PE150-100M）

    		SL-S01547
    *For more proeuct information and specifications please contact us

    Parameter Specifications
    Size 619 mm(W) x 682 mm(D) x738 mm(H)
    Weight 115 Kg
    Power Requirements Input Voltage 100V - 240V~
    Frequency 50 / 60 Hz
    Powe 1000 VA
    Fuse T10AH250V
    Instrument Configuration Display 13.3 inch
    Resolution 1920 x1080
    Operating Environment Temperature 19°C - 25°C
    Humidity 20%RH ~ 80%RH (No Condensation)
    Altitude ≤ 2000m
    Instrument Control Computer CPU 12th Gen Intel(R) core(TM) i9-12900
    Memory 128GB
    Storage 2TB SSD
    OS Windows 10 X64

  • Reads / Run (Up to two chips per run)
    80 M / 150 M / 250 M / 500 M / 1000 M
    Data Output / Run
    4 Gb ~ 600 Gb
    Run Time
    4.8 hr ~ 42 hr
    Applications
    NIPT, Shotgun Metagenomics, Large Panel Sequencing, WES, etc.
    • Highlighted Features
    • Specifications
    • Applications
    • Ordering Information
    • Instrument Specifications


    Sequencing Reagent Set 80M 150M 250M 500M 1000M* Q30**
    SE50 4.0 Gb / 4.8 hr 7.5 Gb / 6 hr 12.5 Gb / 6.6 hr 25.0 Gb / 9 hr / ≥90%
    SE75 6.0 Gb / 6 hr 11.2 Gb /7 hr 18.7 Gb / 7.7 hr 37.5Gb / 12 hr /
    		 ≥90%
    SE100 8.0 Gb / 7.2 hr 15.0 Gb / 8 hr 25.0 Gb/ 9.2 hr 50.0 Gb / 16 hr /
    		 ≥90%
    PE75 / / / 75.0 Gb / 23 hr 150 Gb / 26 hr ≥85%
    PE100 / / / 100.0 Gb / 30 hr 200 Gb / 33 hr ≥85%
    PE150 24.0 Gb / 20 hr 45.0 Gb / 24 hr 75.0 Gb/ 25 hr 150.0 Gb / 42 hr 300 Gb / 45 hr ≥85%

    *The sequencing time is for dual index (8+8);
    *The data throughput mentioned above is for a single chip; Salus Pro can run two chips simultaneously;
    * The time mentioned above is the theoretical sequencing time for a single chip;

    Sequencing Methods Key
    Applications     		Data Volume
    Per Sample     		Read Length 80 M
    Samples / Run     		150 M
    Samples / Run     		250 M
    Samples / Run     		500 M
    Samples / Run     		1000 M
    Samples / Run
    Low-pass
    Whole Genome Sequencing     		NIPT 5 M reads SE 50 16 / 32 30 / 60 50 / 100 100 / 200 -
    CNV-seq / PGT-A 5 M reads SE 75 16 / 32 30 / 60 50 / 100 100 / 200 -
    Small
    Whole Genome Sequencing     		Shotgun Metagenomics 20 M reads SE 75 4 / 8 8 / 16 12 / 25 25 / 50 -
    Microbe, Virus WGS 1 Gb PE 150 24 / 48 45 / 90 75 / 150 150 / 300 300 / 600
    Targeted Sequencing
    (Target Enrichment / Amplicon Sequencing)     		Pathogen Targeted NGS (tNGS) 1 M reads SE 50 80 / 160 150 / 300 250 / 500 500 / 1000 -
    Small Panel Sequencing 1 Gb PE 150 24 / 48 45 / 90 75 / 150 150 / 300 300 / 600
    Large Panel Sequencing 10 Gb PE 150 3 / 6 5 / 10 7 / 15 15 / 30 30 / 60
    WES 12 Gb PE 150 2 / 4 3 / 7 6 / 12 12 / 25 25 / 50
    Methylation Sequencing Multi-cancer Early Detection 4 Gb PE 150 6 / 12 11 / 22 18 / 36 36 / 75 72 / 150
    RNA Sequencing Bulk RNA-seq 6 Gb PE 100 - - - 16 / 32 32 / 64
    Single Cell RNA Sequencing 20 - 50k reads/cell
    (Capture 10000 cells)     		PE 50 + 100 - - - 1 / 5 2 / 10
    Whole Genome Sequencing Human
    Whole Genome Sequencing (30X)     		100 Gb PE 150 - - - 1 / 2 3 / 6

    *Salus Pro can run two chips simultaneously;
    *The number of samples is estimated after careful consideration of library pooling bias and is for reference only

    Explore more
    Products Product Code
    Salus Pro Sequencer SL-Y00125
    Salus Pro Sequencing Reagent Set (SRM-SE50-80M) SL-S00238
    Salus Pro Sequencing Reagent Set (SRM-SE75-80M) SL-S00239
    Salus Pro Sequencing Reagent Set (PRM-PE75-150M) SL-S00247
    Salus Pro Sequencing Reagent Set (PRM-PE150-500M) SL-S00205
    Salus Pro Sequencing Reagent Set (PRM-PE150-1000M) SL-S01510
    *For more proeuct information and specifications please contact us

    Parameter Specifications
    Size 1265mm(W) x 700mm(D) x 675mm(H)
    Weight 210 Kg
    Power Input Voltage 100V - 240V~
    Frequency 50 / 60Hz
    Power 1200VA
    Fuse T15AH250V
    Instrument Configuration Type Capacitive
    Display 21.5 inch
    Resolution 1920x1080
    Operating Environment Temperature 19℃-25℃
    Humidity 20%RH-80%RH (No Condensation)
    Altitude ≤2000m
    Instrument Control Computer CPU Intel Xeon® Silver 4216
    Storage 32 GB DDR4+4
    Memory 10 TB HDD*4; 512 GB+2048 GB SSD
    OS Windows 10 x64
    Maximum sound pressure 75 dB(A)

  • Reads / Run (Up to two chips per run)
    1500 M / 3000 M
    Data Output / Run
    112.5 Gb ~ 1.8 Tb
    Run Time
    9.5 hr ~ 24 hr
    Application
    WES, WGS, Single Cell Sequencning and Spatial Transcriptomics, etc.
    • Highlighted Features
    • Specifications
    • Applications
    • Ordering Information
    • Instrument Specifications

    Sequencing Reagent Set Lanes Read Length 1 x Data / Run 2 x Data / Run Time Q30
    1500 M 4 SE 75 112.5Gb 225 Gb 9.5 hr ≥ 90%
    PE 100 300 Gb 600 Gb 15 hr ≥ 85%
    PE 150 450 Gb 900 Gb 21 hr ≥ 85%
    3000 M* 4 PE 100 600 Gb 1200 Gb 17 hr ≥ 85%
    PE 150 900 Gb 1800 Gb 24 hr ≥ 85%

    *The sequencing time is dual index (8+8);
    *The data throughput mentioned above is for a single chip; Salus EVO can run two chips simultaneously;
    * The time mentioned above is the theoretical sequencing time for a single chip;
    Application 1 x 1500 M
    (Samples / Run)     		2 x 1500 M
    (Samples / Run)     		1 x 3000 M
    (Samples / Run)     		1500 M + 3000 M
    (Samples / Run)     		2 x 3000 M
    (Samples / Run)
    WES
    (15 Gb / Sample)     		30 60 60 90 120
    Large Panel
    (35 Gb / Sample)     		12 25 25 38 51
    WGS
    (100 Gb / Sample)     		4 9 9 13 18
    WGBS
    (100 Gb / Sample)     		4 9 9 13 18
    Single Cell
    (100 Gb / Sample)     		4 9 9 13 18
    Spatial Transcriptomics
    (200 Gb / Sample)     		2 4 4 6 9

    *Salus EVO can run two chips simultaneously;
    *The number of samples is estimated after careful consideration of library pooling bias and is for reference only

    Explore more
    Products Product Code
    Salus EVO Sequencing Reagent Set（SRH-SE75-1500M） SL-S01465
    Salus EVO Sequencing Reagent Set（PRH-PE100-1500M） SL-S01109
    Salus EVO Sequencing Reagent Set（PRH-PE150-1500M） SL-S01113
    Salus EVO Sequencing Reagent Set（PPH-PE100-3000M） SL-S01057
    Salus EVO Sequencing Reagent Set（PPH-PE150-3000M） SL-S01061
    *For more product information and specifications please contact us

    Parameter Specifications
    Dimensions 870 mm(W) × 995 mm(D) × 1616 mm(H)
    Weight 350 Kg
    Power Requirements Input voltage 200 V - 240 V~
    Frequency 50 / 60 Hz
    Power 1200 VA
    Fuse T15AH250V
    Instrument Configuration Type Capacitive
    Display 21.5 inch
    Resolution 1920 x 1080
    Operating Environment Temperature 19°C - 25°C
    Humidity 20% RH - 80% RH (No Condensation)
    Altitude ≤ 2000m
    Instrument Control Computer CPU 2 x AMD7643 (Single 48 core / 96 - thread 2.3 - 3.6G / 225W)
    Memory 1 TB GB DDR4
    Storage 11 TB HDD * 3 ; 512 GB + 3.84 TB * 2 SSD
    OS Windows 10 X64
    Maximum Sound Pressure 75 dB(A)
